Paraffin Wax Technology Master Mixing Valve with Cabinet Assembly

Lead Free Exposed Recirculation Piping Assembly - XL-186-150-LF-DT-RF-R34

ECO-MIX ™ Thermostatic Water Mixing Valve with integral combination checkstops with strainers. 125 PSI (8.6 BAR) maximum operating pressure, Copper encapsulated thermostatic assembly with Stainless Steel shuttle, locking temperature regulating handle. Internal parts stainless steel, integral wall support for easy mounting, Outlet ball valve, Thermometer and pressure gauge on outlet assembly, 3/4" Return loop with thermometer, Ball valve, Leonard 3/4" ARV automatic return valve, (return limiter), Check valves on either side of ARV. Complete unit mounted in a Stainless Steel Cabinet. Valve assembly rough bronze finish, Factory assembled and tested Valve is certified to meet Low-Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contain less than one quarter of one percent of lead by weight.
Inlets 1 1/4"
Maximum Flow(GPM) 130 GPM
Minimum Flow(GPM) 3
Outlet 1 1/2"
Overall Depth 10"
Overall Height 40"
Overall Width 36"
1" Recirculation Piping R1
Baked White Exposed Cabinet BWE-EXP
Baked White Recessed Cabinet BWE-REC
Sight Flow Indicator, ball style SFI
Stainless Steel Exposed Cabinet STSTL-EXP
Stainless Steel Recessed Cabinet STSTL-REC
Megatron Nucleus Installed
